V2200 Industrial Wired Barcode Scanner - RS-232, 6.6' (2m), Straight Cable, and SC Adaptor

Part Number: 178568

Skip past media gallery
V2200 Industrial Wired Barcode Scanner RS232 66 2m Straight Cable and SC Adaptor
Click or press enter to play
Type:
$279.99
(USD) Kit
Part Number: 178568

Added to cart

item added: items added:

  • V2200 Industrial Wired Barcode Scanner - RS-232, 6.6' (2m), Straight Cable, and SC Adaptor
    Color: Green

    Part Number: 178568

    Qty at /
    $0.00
    You save $0.00!

You May Also Like

  • Brady Workstation Design & Print Pro Software - Product, Wire and Lab ID
    Brady Workstation Design & Print Pro Software - Product, Wire and Lab ID from $319.99
  • ToughStripe Max Floor Tape
    ToughStripe Max Floor Tape from $176.99
  • J7300 Industrial Inkjet Color Label Printer WiFi with Software
    J7300 Industrial Inkjet Color Label Printer WiFi with Software from $2,699.00
  • Brady Workstation Design & Print Pro Software - Safety and Facility ID
    Brady Workstation Design & Print Pro Software - Safety and Facility ID from $319.99
  • ToughStripe Max Floor Corner L Marks
    ToughStripe Max Floor Corner L Marks from $76.99
  • BOILER BLOWDOWN Pipe Markers To-Go
    BOILER BLOWDOWN Pipe Markers To-Go from $31.59
Subtotal: $0.00
Shipping and taxes calculated at checkout
View Cart ()

Description

Simplify tasks, reduce errors and program to fit only the functions you need with the rugged, reliable V2200 Wired Barcode Scanner.
  • Delivers consistent, accurate results for any task or skill level, from high-volume warehouse operations to simple data entry
  • Cortex Decoder technology allows scanner to easily read tiny barcodes as well as shiny and hard-to-read surfaces
  • Patented dual-field optics, both high density and wide field, enable scanning of a wide range of barcodes
  • Reliable wired connection ensures continuous operation
  • Rugged design survives 8-foot drops, harsh environments (IP65 rated) and 250 lbs. of crush force
  • JavaScript platform provides unlimited customization options to meet your application needs
  • Data parsing sorts and arranges data for your systems to simplify data entry and improve reporting
  • Cable can be removed and interchanged for different connection needs

Key Features
  • 1D / 2D Barcode Capability: 1D, 2D
  • Field of View: High Density Field: 30° Horizontal by 20° Vertical, Wide Field: 50° Horizontal by 33.5° Vertical
  • Portability: Portable
  • Color: Blue, Gray, Yellow
  • Device Drop Test & Durability: Resistant to 250-lb crushes, Resistant to 8-foot drops, Resistant to military-grade shocks (MIL-STD-810G)
  • Dimensions: 7.795 in H x 3.386 in W x 5.984 in D
  • Sensor: CMOS 1.2 Megapixel
  • Wireless or Wired: Wired
  • Rotational Tolerance: +/- 180°

Specifications

Key Characteristics

Catalog Page # Page number and hyperlink to the digital version of the print catalog. 8
Product Number 178568
UPC 888434644928
UOM Kit
Trade Name V2200
Brand Name Brady®

Dimensions

Dimensions 7.795 in H x 3.386 in W x 5.984 in D
Height 7.795 in
Width 3.386 in
Depth 5.984 in
Cable Length 6.56 ft
Weight 1.28 lb

Material Characteristics

Color Blue, Gray, Yellow

Product Features

Application The type of application or end use environment the product is designed for. Asset Tracking, Barcode Labeling, Circuit Board Labeling, Component and Equipment Labeling, General Identification, Inventory and Inspection Labeling, Warehouse Marking
Shipped With Battery No
Connectivity Options The way in which the printer or scanner can be connected to an external device, PC or Application. RS232, Serial RS232
Device Drop Test & Durability Resistant to 250-lb crushes, Resistant to 8-foot drops, Resistant to military-grade shocks (MIL-STD-810G)
Plug Type US
Power Supply Voltage 100 - 240 V @ 50 - 60 Hz
Scanner Model V2200
Portability Portable
Wireless or Wired Wired
Rotational Tolerance +/- 180°
Sensor The type of sensor used by the Barcode Scanner to read barcodes. CMOS 1.2 Megapixel
Field of View The height and width of a barcode that can be read in one scanning operation, expressed in degrees. High Density Field: 30° Horizontal by 20° Vertical, Wide Field: 50° Horizontal by 33.5° Vertical
Focal Point The specific measured distance between the scanner and the label at which the barcode can be optimally read. Approximately 100 mm
Illumination - Light Source Red LEDs (640 mm)
Power Requirements 10W
Number of Scans Up to 75,000 scans per charge
Optical Resolution Optical resolution describes the ability of an imaging system to resolve detail in the object that is being imaged. This is expressed as a two dimensional result in pixels. High Density Field: 960 x 640, Wide Field: 960 x 640
Pitch The rotation of a bar code symbol about an axis perpendicular to the bars, expressed in degrees. ± 65° (from front to back)
Skew The rotation of a barcode symbol about an axis parallel to the bars, expressed in degrees. ± 60° from plane parallel to symbol (side-to-side)
Target Beam The type of light source used by the Barcode Scanner to scan barcodes. Single Blue targeting bar (470nm)
Type RS-232, 6.6' (2m) Straight Cable
Image Output Options JPEG, PGM
1D / 2D Barcode Capability 1D, 2D
Decode Capability - 1D BC412, Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, GS1 DataBar, Hong Kong 2 of 5, IATA 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, MSI Plessey, NEC 2 of 5, Pharmacode, Plessey, Straight 2 of 5, Telepen, Trioptic, UPC / EAN / JAN
Decode Capability - 2D Aztec Code, Data Matrix, Data Matrix Rectangular Ext'n, GoCode® (prorietary--add'l license req'd), Grid Matrix, HanXin Code, Micro QR Code, QR Code, QR Model 1
Decode Capability - 1D Stacked Codablock F, Code 49, GS1 Composite (CC-A/CC-B/CC-C), MicroPDF, PDF417
Decode Capability - Postal Australian Post, Canada Post, Itelligent Mail, Japan Post, KIX Code, Korea Post, Planet, Post-Net, UK Royal Mail, UPU ID-tags
Field Selection High Density or Wide Field
Advanced Data Editing JavaScript
Symbol Contrast 15% minimum reflectance difference
Ambient Light Immunity Sunlight: Up to 9,000ft-candles/96,890 lux
Charging Station w/BT Radio Communication Interfaces for Barcode Scanners RS232, USB 2.0 (generic HID, HID keyboard, virtual com port)
Data Parsing Driver's licenses and ID Cards (optional license required), GS1, HIBC
Data Structure Validation HIBC UDI, ISO 15418, ISO 15434

What's Included

Includes (1) V2200 Wired Barcode Scanner, (1) RS-232 2m St Cable (178576), (1) AC Adaptor - US
Model V2200
Warranty 3 Years

Compliance

California Prop 65 Proposition 65 (formally titled "The Safe Drinking Water and Toxic Enforcement Act of 1986") is a California law passed by direct voter initiative in 1986. No warning label required
REACH SVHC Status Part does not contain an SVHC
REACH Candidate List Date 25 June 2025
Country of Origin All trade information (i.e. Country of Origin, Harmonized Schedule code, and/or Export Control Classification Number) and related assistance provided by Brady Corporation and its affiliates is provided for informational purposes only and is subject to change without notice. Any use of such information by you is without recourse to Brady Corporation or its affiliates and is at your own risk. This information is not provided as legal advice or as a substitute for obtaining specific legal advice. If you have any questions regarding your specific situation, you should consult your attorney. Malaysia
ECCN (Export Commodity Control Number) All trade information (i.e. Country of Origin, Harmonized Schedule code, and/or Export Control Classification Number) and related assistance provided by Brady Corporation and its affiliates is provided for informational purposes only and is subject to change without notice. Any use of such information by you is without recourse to Brady Corporation or its affiliates and is at your own risk. This information is not provided as legal advice or as a substitute for obtaining specific legal advice. If you have any questions regarding your specific situation, you should consult your attorney. EAR99
HTS Code (Harmonized Tariff Schedule) All trade information (i.e. Country of Origin, Harmonized Schedule code, and/or Export Control Classification Number) and related assistance provided by Brady Corporation and its affiliates is provided for informational purposes only and is subject to change without notice. Any use of such information by you is without recourse to Brady Corporation or its affiliates and is at your own risk. This information is not provided as legal advice or as a substitute for obtaining specific legal advice. If you have any questions regarding your specific situation, you should consult your attorney. 8471.60.8000
Ingress Protection Rating Rating of protection provided against intrusion, dust, accidental contact, and water by mechanical casings and electrical enclosures. IP65
RoHS Compliance Status Compliant with 2011/65/EU with exemptions
UNSPSC United Nations Standard Products and Services Code that is used by manufacturers. 43211701

Drivers, Firmware & Software

Software

Documentation, Guides & Videos

Product Overviews & Specs

  • Industrial Barcode Scanners - Overview Video Industrial Barcode Scanners - Overview Video

Manuals, Guides & How-To

Compliance Documents

You'll find additional compliance information in this page's product specifications and can use this form to request product certifications.

Customers Also Bought

Hardworking and hassle-free

  • Perfect for industrial stationary work spaces — Survives multiple 8 foot drops and water resistant per IP65
  • Designed to match your workflow — Available with USB-A, USB-C or RS-232 connections and straight or longer, coiled cables
  • Easy to set up and customize — Get up and running quickly with our simple configuration tool and helpful tech support

Compare Brady handheld scanners

No matter the industry or environment your work demands — get the right scanner to get the job done right.

  V2200 V3200 V4500
Wired or Wireless Wired Wireless Wireless
IP Rating 65 65 65
Drop Resistance Multiple 8 ft drops Multiple 8 ft drops Multiple 8 ft drops
Crush Resistance 250 lbs 250 lbs 250 lbs
Tumble Resistance (1m) 2,500 2,500 2,500
Illumination Red Red Red
Range (40 mil Code 128) 36.3 in 36.3 in 36.3 in
Range (10 mil Data Matrix) 6.7 in 6.7 in 6.7 in
Custom Programming JavaScript JavaScript JavaScript
Battery Life (scans) Unlimited 100,000+ 75,000+
Bluetooth Range (unobstructed) N/A 300+ ft 300+ ft
Industrial Ethernet Option No
Yes
Yes
Batch Mode No
Yes
Yes
Screen & Keypad No No
Yes
