Overview

TOUGH on the outside, SMART on the inside. The super rugged, ultra intelligent BMP®21-PLUS is an affordable label and wire printer designed for the tool box.

• This handheld label printer creates multi-line labels for clear identification of wires, panels, circuit boards and other industrial items
• On-board keyboard contains letters A to Z and numbers 0 to 9, and backlit LCD graphics display for easier labeling even in low-lit areas
• Prints in 6 different text sizes ranging from 6 point to 40 point in a single color
• Compatible with Brady BMP21 Series printer continuous tape cartridges to enable printing of various styles and widths
• Drop-tested and reinforced with molded-rubber impact bumpers for durability in the most demanding work environments
• Newest firmware update includes: Arial font, 2D barcode printing capabilities, home electrical panel wizard and more
• To receive the Li-Ion battery (BMP21-PLUS-BATT) and AC Adapter/Battery Charger (M-AC-110937), consider the kit: BMP21-PLUS-KIT1

Specifications

Key Characteristics

Key Characteristics	Catalog Page #	104
	Product Number	139535
	UPC	754473928483
	UOM	Each
	Trade Name	BMP®21
	Brand Name	Brady®

Dimensions

Dimensions	Dimensions	9.5 in H x 4.5 in W x 2.5 in D
	Height	9.5 in
	Width	4.5 in
	Depth	2.5 in
	Display Size	2 x 1 in
	Weight	1.66 lb

Material Characteristics

Material Characteristics	Color	Yellow, Gray

Product Features

Product Features	Application	Data and Telecommunications Labeling, Electrical Labeling, General Identification, Lean and 5S Labeling, Warehouse Marking, Wire and Cable Labeling
	Shipped With Battery	No
	Battery Weight	0.21 lb
	Built-In Label Wizards	Flags, Patch Panel, Terminal Block, Wire Wrap
	Connectivity Options	None
	Cutter Type	Single Hand Manual Actuate, Straight Cut, With label retention
	Device Connectivity	Stand-alone
	Device Drop Test & Durability	Resistant to 6-foot drops
	Display Type	Monocolor LCD Screen
	Keyboard Type	ABC, CYRILLIC
	Memory	16 MB (2 MB available for storage, stores 12 labels)
	Number of Symbols	104
	On Screen Indicators	Battery Life
	Plug Type	US
	Power Supply Voltage	110 - 240 V
	Auto Shut-Off / Power Conserve	10 minutes
	Recharge Time	2.5 hours
	User Interface Type	ABC Keypad
	Battery Type	Optional AA Battery, Rechargeable Lithium-ion Battery

Printing Specifications

Printing Specifications	Barcode Symbologies - 2D	Data Matrix, QR code
	Barcode Symbologies - Linear	Code 128, Code 39
	Calibration Required?	Automated through Smart Cell
	Color Printing Capability	Single Color
	Font Sizes	6 - 40 pt
	Font Styles	Brady Standard Font
	Label Retention Feature	Yes
	Maximum Labels per Day	100
	Maximum Label/Tape Width	0.75 in
	Maximum Print Speed	0.4 in/s
	Maximum Printed Label Length	36 in
	Print Resolution	203 dpi
	Print Technology	Thermal Transfer

Compatibility

Compatibility	Compatible Media	M21-
	Label Material Types	Heat-shrink Polyolefin, Nylon Cloth, Paper, Polyester, Polypropylene, Self-laminating Polyester, Self-laminating Vinyl, Vinyl
	Materials Supported	Continuous
	Custom Labels Available	No
	Maximum Print Width	0.63 in
	Languages Available	Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (France), German, Hungarian, Italian, Norwegian, Polish, Portuguese (Portugal), Romanian, Slovak, Slovenian, Spanish (universal), Swedish, Turkish

What's Included

What's Included	Includes	(1) BMP®21-PLUS Printer (BMP21-PLUS), (1) BMP21 Plus Series Nylon Cloth Patch Panel and Wire and Cable Labels (M21-750-499), (1) Quick Start Guide
	Model	BMP21 PLUS
	Warranty	2 Years

Compliance

Compliance	California Prop 65	Due to inconclusive data, this product may not ship to California at this time
	REACH SVHC Status	Please contact our CS department for more information
	REACH Candidate List Date	Please contact our CS department for more information
	Country of Origin	Malaysia
	ECCN (Export Commodity Control Number)	EAR99
	HTS Code (Harmonized Tariff Schedule)	8443.39.9000
	Patent Number(s)	6.604.874, 6.732.619, US 8.322.936
	RoHS Compliance Status	Please contact our CS department for more information
	UNSPSC	45101520
