Description

Get everything you need to automate your vial identification in one complete kit with the BradyPrinter i7100 Vial Applicator Kit.
  • Get the job done with the BradyPrinter i7100 label printer. No matter the demands, this reliable, heavy-duty and high-accuracy label printer gets it all done
  • BradyPrinter i7100 Vial Applicator easily applies to vials during your high-volume identification projects
  • Save up to 5% when you buy the kits vs. buying each piece individually
  • Using printed labels allow for precision tracking by eliminating error-prone, handwritten labels
  • Vial applicator pays for itself after approximately 100 hours of use
  • Wide-ranging variations exist in size, material, and cap characteristics for tubes and vials. Users should test their label and tube combination to their intended workflow process, print job attributes, label content, and post-application environmental exposure
  • Tube/Vial orientation at labeling time: horizontal
  • Vial diameter size range: .39"-.86" (10-22mm) / Vial length size range (cap included): .98"-4.72" (25-120mm)

Key Features
  • Maximum Labels per Day: 5000
  • Device Connectivity: PC connected & Stand-alone
  • Print Technology: Direct Thermal, Thermal Transfer
  • Color Printing Capability: Single Color
  • Maximum Label/Tape Width: 4.16 in
  • Software Package: Product & Wire ID

Specifications

Key Characteristics

Product Number 151753
UPC 888434557068
UOM Kit
Trade Name BradyPrinter i5100
Brand Name Brady®

Dimensions

Dimensions 12.5 in H x 9.5 in W x 17.2 in D
Height 12.5 in
Width 9.5 in
Depth 17.2 in
Core Diameter 3 in
Display Size 2 x 3.6 in
Weight 13.6 lb

Material Characteristics

Color Blue, Gray

Product Features

Application The type of application or end use environment the product is designed for. Asset Tracking, Circuit Board Labeling, General Identification
Connectivity Options The way in which the printer or scanner can be connected to an external device, PC or Application. Ethernet, RS232, USB 2.0, USB Host
Device Connectivity Device Connectivity: Stand-alone (no computer or mobile app required to operate), PC connect, or mobile app. Some devices have multiple connectivity options. PC connected & Stand-alone
Display Type Color LCD Touch Screen
Keyboard Type None
Media Sensor Type Black Mark, Gap Sensor, Notch, Reflective Sensor
Memory 256 MB RAM, 50 MB IFFS Flash
On Screen Indicators Bluetooth Status, Data Reception, Data Recording, Digital Clock, Ethernet Status, Print Mode: Brady or Standard, Ribbon and label part number recognition, Ribbon Remaining, SD Memory Card inserted, Sensor: selection and positioning, Supply Remaining, USB Memory Stick inserted, USB Slave Status, WLAN Field Intensity
Plug Type US
Power Supply Voltage 100 - 240 V @ 50 - 60 Hz
Auto Shut-Off / Power Conserve Yes
User Interface Type PC, Touch Screen
Battery Type Lithium-manganese Battery
Operating System Windows® 10, Windows® 7, Windows® 8, Windows® Server 2012, Windows® Server 2012 R2, Windows® Server 2016

Printing Specifications

Automatic Label Set Up Printer can automatically sense and align labels. Yes
Barcode Symbologies - 2D Aztec, Data Matrix, GS1 DataMatrix, MaxiCode, MicroPDF417, PDF417, QR Code
Barcode Symbologies - Linear Codabar (NW-7), Codablock F, Code 128, Code 39, Code 93, Deutsche Post (Identcode/Leitcode), EAN/JAN-13, EAN/JAN-8, EAN/UPC, FIM, GS1 DataBar, GS1 DataBar Expanded and GS1 DataBar Limited, GS1 DataBar Stacked and GS1 DataBar Truncated, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Truncated, GS1-128, Interleaved 2 of 5, MSI Plessey, POSTNET, UPC-A, UPC-E
Calibration Required? Printer requires manual calibration for optimal performance. Yes
Color Printing Capability Single Color
Font Styles Bitmap Default Font - 12x12 dots, Bitmap Default Font - 16x16 dots, Bitmap Default Font - 16x32 dots, Monospace 821, OCR-A Size I, OCR-B, Swiss 721, Swiss 721 Bold
Maximum Labels per Day Estimated throughput based on a typical work week (8 hrs/day, 5 days/week). Actual results may vary due to label size, material, print speed, and content. 5000
Maximum Label/Tape Width For custom materials, consult technical documentation for printing specifications 4.16 in
Maximum Print Speed 5.9 in/s
Minimum Label Length Test for your application. Small label performance varies based on print speed, quantity per print run, heat setting, and size and layout of the printed content. 0.2 in
Maximum Printed Label Length 6.6 ft
Print Technology Direct Thermal, Thermal Transfer
Progamming Language abc Basic Compiler, Database Connector, Jscript, SAP Integration, ZPL Emulator
Media Sensor Adjustment Yes

Compatibility

Compatible Media The corresponding media series: Parts with this prefix are compatible with the printer. 2HT-, 3HT-, 3PS-, PS-, PSL-, THT-, THTCLP-, THTEP-, THTFP-, THTFT-, XTHT-
Label Material Types Direct Thermal Paper, FreezerBondz™ Polyester, Heat-shrink Polyolefin, High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Metallic, Non-metal Polyester, Metallized Polyester, Metallized Polyester with Polyester Overlaminate, Nylon Cloth, Paper, Polyester, Polyester with Polyester Overlaminate, Polyethylene Foam Laminate Polyester, Polyimide, Polyolefin, Polypropylene, Polyvinylfluoride, Repositionable Paper, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-evident Metallized Polyester, Tamper-evident Polyester, Tamper-resistant Metallized Vinyl, Tamper-resistant Vinyl, Vinyl, Vinyl Cloth, Water-indicating Polyester/Paper Laminate
Materials Supported Bulk, Custom, Die-cut
Custom Labels Available Yes
Maximum Print Width 4.16 in
Software Compatibility Brady Workstation, Windows based driver for 3rd party software use
Languages Available Bulgarian, Chinese (Simplified), Croatian, Czech, Danish, Dutch, English (US), Farsi, Finnish, French (France), German, Greek, Hungarian, Italian, Korean, Lithuanian, Macedonian, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Serbian, Slovenian, Spanish (Spain), Swedish, Turkish

What's Included

Software Package Product & Wire ID
Includes (1) Brady Workstation Product and Wire ID Software Suite (BWS-PWID-EM)<br>, (1) Configuration Settings Manual, (1) i7100 300 dpi Peel Model Printer (149053), (1) Owners Manual, (1) Product CD with Driver, (1) U.S. Type B Plug Power Cord, (1) USB Cable, (1) Vial Label Applicator, (2) 1 In Ribbon Takeup Cores
Model i7100
Warranty 5 Years

Compliance

California Prop 65 Proposition 65 (formally titled "The Safe Drinking Water and Toxic Enforcement Act of 1986") is a California law passed by direct voter initiative in 1986. Prop 65WARNING: Risk of cancer and reproductive harm from exposure to Lead. See www.p65warnings.ca.gov.
REACH SVHC Status Part does not contain an SVHC
REACH Candidate List Date 07 November 2024
Country of Origin All trade information (i.e. Country of Origin, Harmonized Schedule code, and/or Export Control Classification Number) and related assistance provided by Brady Corporation and its affiliates is provided for informational purposes only and is subject to change without notice. Any use of such information by you is without recourse to Brady Corporation or its affiliates and is at your own risk. This information is not provided as legal advice or as a substitute for obtaining specific legal advice. If you have any questions regarding your specific situation, you should consult your attorney. Germany
ECCN (Export Commodity Control Number) All trade information (i.e. Country of Origin, Harmonized Schedule code, and/or Export Control Classification Number) and related assistance provided by Brady Corporation and its affiliates is provided for informational purposes only and is subject to change without notice. Any use of such information by you is without recourse to Brady Corporation or its affiliates and is at your own risk. This information is not provided as legal advice or as a substitute for obtaining specific legal advice. If you have any questions regarding your specific situation, you should consult your attorney. EAR99
HTS Code (Harmonized Tariff Schedule) All trade information (i.e. Country of Origin, Harmonized Schedule code, and/or Export Control Classification Number) and related assistance provided by Brady Corporation and its affiliates is provided for informational purposes only and is subject to change without notice. Any use of such information by you is without recourse to Brady Corporation or its affiliates and is at your own risk. This information is not provided as legal advice or as a substitute for obtaining specific legal advice. If you have any questions regarding your specific situation, you should consult your attorney. 8443.32.1050
RoHS Compliance Status Compliant with 2011/65/EU with exemptions
UNSPSC United Nations Standard Products and Services Code that is used by manufacturers. 45101519

Drivers, Firmware & Software

Drivers & Firmware

Documentation, Guides & Videos

Product Overviews & Specs

  • BradyPrinter i7100 Vial Label Applicator video BradyPrinter i7100 Vial Label Applicator video

Manuals, Guides & How-To

Customers Also Bought

Unwavering performance for demanding jobs

The BradyPrinter i7100 Industrial Label Printer is built to tackle your toughest labeling challenges. This reliable, heavy-duty, and high-accuracy printer is designed to produce thousands of labels daily, handling even the most difficult-to-print materials with confidence. You'll achieve ultra-sharp prints on labels as small as 0.125 inches, all controlled by an easy-to-use touchscreen interface.

Take the stress out of setup

Our complimentary Stress-Free System Setup Service helps you get up to speed on how to use your new printer and software, so you can start printing immediately.

Learn More

Top applications

General Identification
Directional marking, Equipment labeling
Wire & Cable
Sleeves, Self-Lams, Wire Wraps, Flag Labels, Cable Markers
Rating & Name Plate
Durable finished goods, High quality barcode images and text, UL certification
Circuit Board
ESD labels, Polyimide circuit board labels
Electrical
Sleeves, Self-Lams, Wire Wraps, Cable Markers, Flag and Raised Panel Labels
